Scalarworks PEAK Fixed Rear Sight
Video | What’s Included | Specs | Pictures | Restrictions
While optics have advanced tremendously over the past few decades, iron sights are still very much the same. To keep up with modern optics, Scalarworks created the PEAK iron sights. They’re designed to interface with modern carbines in a way that older fixed irons simply do not, in that the PEAK adjust in the same increments as most red dot optics (0.5 MOA/click). When acquiring zero with our Zero Target, all the adjustment data listed on the target applies to both your red dot optic and the PEAK iron sights.
OVERVIEW VIDEO
WHAT’S INCLUDED
- 1x Scalarworks PEAK/01 fixed rear sight
We include an 8.5″ x 11″ rifle zero target with every iron sight. We recommend a 50/200 meter zero for most 5.56 rifles. (Click on the thumbnail for a printable version)
How To Shoot Part 2: Zeroing – Video – T.REX ARMS
SPECS
TECHNICAL SPECIFICATIONS
| Materials | 7075-T6 Aluminum / 4140H Steel |
| Finishes | Type III Black Anodizing / Flash Nitride |
| Center height over rail | 1.42″ |
| Adjustments | 0.5MOA/Click @ 15″ sight radius |
| Adjustment range | 46MOA windage @ 15″ sight radius |
| Weight | 1.44oz |
| Flip apertures | Same-plane 0.07″/0.20″ diameter |
Made in The USA.
View the User Manual HERE.
PICTURES
RESTRICTIONS
Scalarworks products cannot be shipped outside of the US.
